TDK-Lambda ZERO-UP 200W - Controls and Indicators; Front Panel

This chapter describes the operating modes, controls and indicators of the ZUP power supply series.
Details of local operation via the front panel and various modes of operation are described in this
chapter, including remote analog control via the rear panel. For computer control via the Serial port
(RS232 or RS485), refer to chapter 5.
CHAPTER 4 OPERATING INSTRUCTIONS
4.1 INTRODUCTION
4.2 CONTROLS AND INDICATORS
4.2.1 Front panel
Fig. 4-1: Front panel controls and indicators
8
9
10
11
12
13
1
2
3
7
4
6
5
