TDSi MICROgarde II User Manual

04. 20.11.18 MICROgarde controller I and II Page 11
2.3.2
Recommended cable types
Component Part No. Cable Type Cores Maximum Distance
Magnetic Stripe Reader 5002-0360
Belden 9730
6
60m
Belden 9503
6
25m
OS6C24/Alpha 5096/BICC H8124 6 20m
Screened Alarm Cable 8 Up to 30m
EXprox / EXprox2 5002-0354
5002-0355
Belden 9730
6
150m
Belden 9503 6 150m
OS6C24/Alpha 5096/BICC H8124 6 150m
Screened Alarm Cable
8
150m
Optica 5002-0390
5002-0391
Belden 9730 6 150m
Belden 9503 6 150m
OS6C24/Alpha 5096/BICC H8124 6 150m
Screened Alarm Cable 8 150m
Digital IR 5002-1781
5002-1791
Belden 9730
6
150m
Belden 9503 6 150m
OS6C24/Alpha 5096/BICC H8124
6
150m
Screened Alarm Cable 8 150m
MIFARE / EXsmart2 5002-0433
5002-0434
5002-0435
5002-0436
5002-0440
5002 0441
Belden 9730
6
150m
Belden 9503
6
150m
OS6C24/Alpha 5096/BICC H8124 6 150m
Screened Alarm Cable
8
150m
DIGIgarde /
DIGIgarde Smart /
PALMgarde
5002-0450
5002-0451
5002-0460
Belden 9730 6 150m
Belden 9503 6 150m
OS6C24/Alpha 5096/BICC H8124
6
150m
Screened Alarm Cable 8 150m
Indala Proximity Reader 5002-0133
5002-0137
5002-0217
5002-0218
Belden 9730
6
150 m
Belden 9503
6
60 m
OS6C24/Alpha 5096/BICC H8124 6 60 m
Screened Alarm Cable 8 Up to 30m
Dataline Keypad 5002-0286
5002-0315
5002-0316
Belden 9729
4
140m
FBOS2P24 4 100m
OS2P22/Alpha 5902/Belden 9502
4
60m
OS4C24/Alpha 5094/BICC H8123 4 40m
RS-232 7/0.2 mm 3– core screened cable 3 15m
RS-485
1
Belden 9729
4
1200m
FBOS2P24 4 900m
OS2P22/Alpha 5902/Belden 9502 4 530m
OS4C24/Alpha 5094/BICC H8123 4 400m
Screened Alarm Cable 8 300m
Inputs 7/0.2mm (screened) 2 300m
Relays 7/0.2mm or 16/0.2mm (screened) 2 Dependent on load and
cable choice
1
Up to 32 MICROgarde access control units can be connected to a single port.
