DC-HV-Cable : Cross-section 1 x 16,0mm²
Supplier: Coroplast
Outer Diameter 10,2
-0,6
mm
Cable description: FHLR2GCB2G 16mm²/0.21 T180 0.6/0.9kV
acc. LV216-2 Tab. A.2
Part No.: 9-2611 / 16mm²
DC-HV-Cable : Cross-section 1 x 50mm²
Supplier: Coroplast
Outer Diameter 15,8
- 0,6
mm
Cable description: FHLR2GCB2G 50mm² / 0.21 T180 0.6/0.9kV
acc. LV216-2 Tab.A.2
Part No.: 9-2611 / 50mm²
4. APPLICATION TOOLS
Required application tools are:
Minimum requirements for the press are 20t.
Wire
Type
Wire
Size
[mm²]
Construction
Stripping
Length
[mm]
Crimp
height
CH
1
[mm]
Wire std
Specification
Supplier
Contact P/N
Geometry
Applicator
Crimping press used
by TE for Product
Validation
Pure
copper
6
84 x 0.31mm
13,0 ± 1
3,7 ±0,1
LV216-2
FHLR2GCB2G
3x6.0mm²
Coroplast
2293266-3
2-2293266-3
W
7-528041-0
HV Crimping Machine
528008-4 with adapter
or
HV-20
2348822-1
1
Cycle time: 1.7 - 2.5s
Stroke: 44mm
2293266-4
16
512 x 0.21mm
16,0 ± 0,5
5,10 ±0,1
LV216-2
FHLR2GCB2G
single
Coroplast
2292541-4
2-2292541-4
W
2276149-2
500 x 0.21mm
16,0 ± 0,5
5,10 ±0,1
LV112-1
FLY single
Coficab
2293267-4
2-2293267-4
W
2276149-7
50
1600 x
0.21mm
23,5 ±0,5
9,4±0,15
LV216-2
FHLR2GCB2G,
single
Coroplast
2292541-1
W
2276149-4
Crimp
Ferrule
50
1600 x
0.21mm
See step
5b
15.3 ±0.1
LV216-2
FHLR2GCB2G,
single
Coroplast
2316553-2
-
8-528041-2
or
2234183-1
1
recommended for new projects using modular die sets
Table 1
