2. PRINTER SETUP ENGLISH VERSION
2.5 Connecting the Power Adapter and the Power Cord
2.5 Connecting the
Power Adapter and
the Power Cord
1. Make sure that the printer power switch is in the OFF (O) position.
2.
Insert the Power Cord into the inlet of the Power Adapter.
Power Cord
3. Insert the
Power Adapter connector into the Power Jack on the rear of the printer.
Power Adapter
Power Adapter
Connector
Power Jack
2- 5
