2.9 Media Sensor Calibration, Self Print Test, and Dump Mode Utilities
2.9.2 Self Print Test and
Dump Mode
1. Turn off the printer power and install a media roll on the printer.
2. Press the [FEED] Button while turning on the printer. The Indicator
Lamp will light up in the following order:
Green (Flashing) → Red (Flashing) → Orange
(Flashing)
→ Orange → RED → Green
3. Release the [FEED] Button when the Indicator Lamp lights up in
green.
4. The printer automatically performs a self print test, and then enters the
Dump Mode.
5. To start the Online operation, turn the printer off, then on again .
Print test label sample
NOTE :
The f
ollowing commands should
not affect the test print issue.
D
, AX, XS, Z2;1, Z2;2 (without
A
Y)
PRINTER INFO.
PROGRAM VERSION VX.XX XXXX
TONE ADJUST +XX
FEED ADJUST +XX.Xmm
CUT POSITION ADJUST +XX.Xmm
BACKFEED ADJUST +XX.Xmm
PARAMETER [ PC-850 ] [ 0 ]
[ 9600 ] [ 8 ] [ 1 ] [ NONE ] [ 2 ]
[ ON ] [ AUTO ] [ FEED ] [ B0 ] X-
COORDINATE ADJUST +XX.Xmm
SENSOR SELECTION TRANSMISSIVE
SENSOR ADJ. VALUE TRANSMISSIVE [XX] REFLECTIVE [XX]
PRINT SPEED 5 IPS
FLASH ROM 4 MB
SDRAM 8 MB
USER MEMORY [ X KB][ 0 KB]
TTF AREA [ 0 KB][ 0 KB]
EXT CHAR AREA [ 0 KB][ 0 KB]
BASIC AREA [ 0 KB][ 0 KB]
PC SAVE AREA [ X KB][ 0 KB]
INFORMATION
TOTAL FEED 0.00 km
TOTAL PRINT 0.00 km
TOTAL CUT 0
IP ADDRESS 192.1 68.1 0.20
SUBNET MASK 255.255.255.0
GATEWAY 0.0.0.0
MAC ADDRESS XX-XX-XX-XX-XX
DHCP Disabled
DHCP CLIENT ID FFFFFFFFFFFFFFFFFFFF
FFFFFFFFFFFF
SOCKET COMM. Enabled
SOCKET COMM. PORT 08000
