TE Connectivity T200 - Interior

1. PRODUCT OVERVIE
W
ENGLISH VERSION
1- 4
1.5 Appearance
1.5.4 Interior
Media Guide
Adjustment Dial
Ribbon Rewind Gear
Ribbon Access Cover
Feed Gap Sensor (Transmitter)
Black Mark Sensor
Platen
Spring Guide Wheel (Take-up side)
Spring Guide Wheel (Supply side)
Media Holder Lock Switch
Feed Gap Sensor
(Receiver)
Media Holder
Top Cover
Print Head
WARNING!
Do not touch the print head or
around it just after printing.
You may get burned as the
p
rint head becomes very hot
during printing.
Media Guide
Cover Open Sensor
