2. PRINTER SETUP ENGLISH VERSION
2-16
2.8 Loading the Ribbon
2.8 Loading the Ribbon 6. Close the Ribbon Access Cover until it clicks.
(Cont.)
7. Again, turn the Ribbon Rewind Gear to remove any slack of the
ribbon.
Print Head
Block
Ribbon Access
Cover
Ribbon
Rewind Gear
8. Close the Top Cover gently and push down the front part of the Top
Cover until they click.
Now, the ribbon loading is completed.
