Amplifier Section
Output Power (Front):
RMS Power (40 Hz – 20 kHz):
130 watts/8 ohms, 0.09%
Surround Output Power (0.5 % THD, 1 kHz, 8 ohms):
100 + 100 watts (Front)
100 watts (Center)
100 + 100 watts (Rear)
Total Harmonic Distortion (Front):
0.02 % (at 120 watts, 1 kHz)
Delay Time:
DOLBY DIGITAL: REAR 0 – 15 ms
: CENTER 0 – 5 ms
DOLBY PRO LOGIC: REAR 15 – 30 ms
Audio Input Sensitivity/Impedance:
PHONO: 2.5 mV/47 k ohms
*
LINE: 220 mV/47 k ohms
Output Level/Impedance:
TAPE 1/2 REC: 200 mV/2.2 k ohms
Frequency Response:
PHONO: 20 Hz – 20 kHz, ±1 dB
*
LINE: 20 Hz – 65 kHz, +1/ –3 dB
Signal-to-Noise Ratio:
PHONO: 70 dB (IHF-A)
*
LINE: 95dB (IHF-A)
Tone Control:
BASS: ± 10 dB at 100 Hz
TREBLE: ± 10 dB at 10 kHz
Digital Audio Section
Sampling Frequency:
DIGITAL 1/2: 32 kHz, 44.1 kHz, 48 kHz, 96 kHz
DIGITAL 3: 32 kHz, 44.1 kHz, 48 kHz,
DIGITAL Input Level/Impedance:
DIGITAL 1 (COAXIAL): 0.5 Vp-p / 75 ohms
DIGITAL 2/3 (OPTICAL): –15 dBm — –21 dBm
Video Section
Input Sensitivity/Impedance:
1.0 Vp-p/75 ohms
Output Level/Impedance:
1.0 Vp-p/75 ohms
FM Tuner Section
(Without notes 100.1 MHz, 65 dBf)
Tuning Range: 87.5 MHz – 108.0 MHz (50 kHz steps)
Usable Sensitivity (IHF): Mono: 15 dBf
50 dB Quieting Sensitivity:
Mono: 23 dBf
Stereo: 40 dBf
Capture Ratio: 2.0 dB
Image Rejection Ratio: 80 dB
AM Suppression Ratio: 55 dB
Total Harmonic Distortion (1 kHz):
Mono: 0.4%
Stereo: 0.5%
Frequency Response: 30 Hz – 15 kHz, +1/ –1.5 dB
Stereo Separation (1 kHz): 40 dB
Signal-to-Noise Ratio:
Mono: 75 dB
Stereo: 70 dB
AM Tuner Section
Tuning Range: 522 kHz – 1,620 kHz (9 kHz steps)
Usable Sensitivity: 55 dB/m
Total Harmonic Distortion: 0.8% at 85 dB/m
Signal-to-Noise Ratio: 45 dB at 85 dB/m
General
Power Requirements: 230 V AC, 50 Hz
Power Consumption: 320 W
AC Outlets: Switched x 2, 100 W max.
Dimensions (W x H x D): 435 x 165 x 400 mm
Weight (net): 10.7 kg
Standard Accessories:
AM Loop Antenna x 1
FM Lead-type Antenna x 1
Remote Control Unit (UR-416) x 1
<
*
LINE means CD, MD/TAPE 1, TAPE 2, VCR/VIDEO 1,
LD/VIDEO 2, AUX/VIDEO 3 and DVD/VIDEO 4.
< Improvements may result in specifications and features
changing without notice.
< Illustrations may differ slightly from production models.
