IV. TECHNICAL SPECIFICATION
TUNER
Input frequency 174 to 860MHz UHF & VHF
Bandwidth 7 or 8 MHz
Input level -72 to -20dBm
Input impedance 75Ω
CHANNEL DECODING
Demodulation QPSK,16QAM,64QAM
FEC 1/2, 2/3, 3/4, 5/6, 7/8.
Mode 8K or 2K
Guard Band 1/4, 1/8, 1/16, 1/32
DEMULTIPLEXER
Standard ISO/IEC 13818-1
Input max. bit stream rate 60Mbps (Serial) /7.5MBps (Parallel)
VIDEO DECODING
Standard ISO/IEC 13818-2
Aspect ratio modes 16:9, 4:3 Centre Cut and 4:3
Video output resolution modes 576i 576p 720p 1080i
AUDIO DECODING
Standard ISO/IEC 13818-3
Output modes Stereo, Left, Right.
Sampling frequencies 32, 44.1, 48KHz
AV OUTPUT
Video de-emphasis CCIR REC.405-1, 625LINES
Video bandwidth 5.5 MHz
Video output impedance 75Ω
