33
ENGLISH
Specifications Messages
TRACK 0 0:00
A blank CD-R/CD-RW disc is set on the tray.
bUSY
The unit is reading the disc. Wait a few seconds.
CLOSE
Close the disc tray.
ErASE
Erase the last track of the CD-RW disc.
ErASEALL
Erase all the tracks of the CD-RW disc.
FINAL
Finalize the disc.
–40db, –30db or –20db
Settings of the track number assignment mode
NO dISC
No readable disc has been loaded.
OPEN
Open the tray.
- - - -:- -
The unit is reading the disc.
P-**
Program number
UnFINAL
Unfinalize the CD-RW disc.
Error Messages
d FULL, OPFULL
There is no space on the disc, or no more tracks are available.
P-FULL
32 tracks have been programmed. No more tracks can be
programmed.
Err **
An error occurred within the unit.
Press the POWER switch to turn the unit off, wait a minute, and
turn it on again.
Err 03
Something is wrong with the disc.
Turn the unit off and on, and change the disc.
dISC Err
An error disc or irregular-shaped disc has been loaded.
DAO DISC
The unfinalize function cannot be performed with discs recorded
using the "Disc at Once (DAO)" recording system.
(** is variable.)
Amplifier Section
Output power ....................................3.5 W + 3.5 W
Frequency response ............................50 Hz to 20 kHz
Audio input sensitivity/Impedance ............AUX: (0.5 V)/20 kΩ
CD Recorder Section
Media type ...................CD-RW and CD-R for Digital audio
(record and playback)
CD (playback only)
Recording sampling frequency .........................44.1 kHz
Frequency response .................... 20 Hz to 20 kHz (±3 dB)
Signal to noise ratio ................. More than 85 dB (playback)
More than 75 dB (recording)
Cassette tape section
Tracking system ........................4-track, 2-channel stereo
Tape speed ..........................................4.8 cm/sec
Wow&flutter ...............................................0.3%
Frequency characteristic .......................125 to 10,000 Hz
S/N ratio ..................................................45 dB
Tuner Section
Frequency range (FM) ....................87.5 MHz to 108.0 MHz
Frequency range (AM). . . . . . . . . . . . . . . . . . . . . . 522 kHz to 1,629 kHz
Record Player Section
Motor ..........................................DC servo motor
Drive system ..........................................Belt Drive
Speed ..............................33-1/3 rpm, 45 rpm, 78 rpm
Wow and Flutter ...........................less than 0.3% (WDT)
Signal to noise ratio ............................More than 50 dB
Cartridge type .........................Ceramic Stereo Cartridge
Stylus ..................STL-103 (premounted) / SPL-102 (option)
Output level .....................158 - 348 mV (50 mm/S, 1 kHz)
Speaker System Section
Unit .................................................76 mm (3”)
Impedance .............................................4 ohms
GENERAL
Power requirements ................................230V, 50 Hz
Power consumption ...................................... 25 W
Dimensions (W x H x D) .....................470 x 230 x 390 mm
Weight ...................................................11 kg
Operating temperature range .......................5°C to 35°C
Accessories
Owner’s manual x 1
Warranty card x 1
45 RPM adaptor x 1
Remote control unit (RC-1157) x 1
Battery (AA, alkaline or MN) x 2
FM antenna x 1
AM antenna x 1
Hinge x 2
Turntable cover x 1
Quick Start Guide for recording x 1
Stereo RCA pin cable x 1
< Design and specifications are subject to change without notice.
< Weight and dimensions are approximate.
< Illustrations may differ slightly from production models.
