14
Names and functions of parts (main unit)
A Level meters
These show the output levels.
B Disc tray
Load a disc here.
C POWER switch
Use to turn the unit on and off (page 18).
o If the display or level meters are dark even though the
POWER switch is set to ON, one of the following conditions
is possible.
o The power is on, but the display brightness is set to
DIMMER 0 and/or the level meter operation setting is
DIM0 or OFF (page 26).
o The automatic power saving function has activated, put-
ting the unit into standby (page 27).
o The power cord is disconnected.
D SOURCE knob
Use to select the input source.
Use to change setting values when a menu item is shown.
Turn when the menu is open to change the item shown or the
setting value.
E ENTER button
Press to confirm the selected item.
o Press when the unit is in standby to turn it on (page 19).
F MENU button
Use to enter setting mode (page 25).
Press when in setting mode to change the setting item.
G UPCONVERT button
Use to show and change the upconversion setting (page 16).
H Display
This display shows information about the audio playing back
and menu screens (page 17).
I Stop (8) button
Press to stop CD, NET or Bluetooth playback.
J Play/pause (7/9) button
When the input source is CD, NET or Bluetooth and playback is
stopped or paused, press to start playback.
Press during playback to pause.
K Remote control signal receiver
This receives signals from the remote control. When operating
the remote control, point it at the remote control signal receiver.
