Teac NR-7CD - Upconversion

16
Upconversion
The conversion function can be used when digital audio is being
input (CD, NET*, Bluetooth, OPT1, OPT2, COAX).
Press the UPCONVERT button to show the current setting.
Press it again to change the upconversion setting.
*For USB flash drive playback, set the input source to NET.
OFF
DSD
2Fs
4Fs
8Fs
Display example
UPCONV
DSD
OFF
Upconversion will not occur.
The original input signal is sent as is directly to the D/A converter.
DSD
2Fs
4Fs
8Fs
The upconversion shown will be used.
The relationships between input sampling frequencies and sam-
pling frequencies after upconversion are as follows.
Input source Upconversion setting
Input sampling
frequency
OFF 2Fs 4Fs 8Fs DSD
Sampling frequency after upconversion
[kHz] [kHz] [MHz]
32 32 64 128 256 8.0
44.1 44.1 88.2 176.4 352.8 11.2
88.2 88.2 88.2 176.4 352.8 11.2
176.4 176.4 176.4 176.4 352.8 11.2
352.8 352.8 352.8 352.8 352.8 11.2
48 48 96 192 384 12.2
96 96 96 192 384 12.2
192 192 192 192 384 12.2
384 384 384 384 384 12.2
DSD [MHz] [MHz] [MHz]
2.8 2.8 2.8 2.8 2.8 2.8
5.6 5.6 5.6 5.6 5.6 5.6
These values are not converted.
