32 | PowerMax-HP10
CONNECTING THE POWERMAX-HP10
Caution!
Before connecting the system, switch off the power of the
PowerMax-HP10 and other equipments power sources.
1. Connecting DVD players
An external DC power supply is required. Connect a 7.5V DC
power supply to the 7.5V DC input jack on the back of the 5.1
amplifier box.
DVD players are connected to the input jacks Front, Rear, Sub/
Center over the 6 RCA output jacks. The connection is provided
by a DVD and a PC cable.
Optionally a 5.1 amplifier/speaker system can be connected to
the pass-through 5.1-output connectors of the headphone am-
plifier. It provides the DVD signal for further playback devices. TV
sound can be connected to the input AUX using a TV cable.
For power and signal connection method, please refer to the
following picture.
