40 | PowerMax-HP10
SPECIFICATION 5.1-CHANNELS AMPLIFIER
Compatible to DVD, PC, VCD, CD, TV, MP3, CD-R, CD-DA
Audio Inputs AUX (Stereo) 1 Set
DVD (5.1-channel) 1 Set
Audio Outputs 6 Channels 1 Set
Audio Specifications Front, Rear, Center. 20Hz-20kHz
Subwoofer 20Hz-120Hz
Signal/Noise ratio >=80dB
Selection >-60dB
Distortion <0.5%
Power supply AC/DC power supply 230/7.5V, 500mA, 3.75W
USB power 5.0V, 500mA, 2.5W
Dimensions (W x D x H) 90 x 155 x 143 mm
Weight amplifier approx. 450g
Operation Temperature 0-40 °C
Operation Humidity rel. <90%
Weight cables approx. 100g
SPECIFICATION 5.1-CHANNELS HEADPHONE
Power capacity 500mW x 6
Weight approx. 300g
Speaker Driver Front Diameter 40 mm (x 2)
Impedance 64 Ohms
Frequency Range 20Hz-20k Hz
Speaker Driver Rear Diameter 30 mm (x 2)
Impedance 32 Ohms
Frequency Range 20Hz-20k Hz
Speaker Driver Center Diameter 30 mm (x 2)
Impedance 32 Ohms
Frequency Range 20Hz-20 k Hz
Speaker Driver Vibration Diameter 30 mm (x 2)
Impedance 8 Ohms
Frequency Range 20Hz-120 Hz
SPECIFICATION MICROPHONE
Type Electret-Capsule 9.7mm
Weight approx. 30g
Directivity Omnidirektional
Impedance 2200 Ohms +/- 15%
Sensitivity 60dB +/- 2dB
Frequency Range 30Hz- 16,000Hz
Operation Voltage nominal 4.5V
