CONTROL BUTTONS DEFINITION AND FUNCTION
Front Plate Back Plate
1. Power On/Off (On/
Standby) Button
2. Master Volume Knob
3. DVD/AUX source selector
switch
4. Channel Indication Light
5. 5.1 Channel Headphone
outputs
6. AUX (Stereo) Audio Input
7. DVD (5.1 channel) Audio
Input
8. Audio Extension Output
9. DC Power Source (7.5 V
adaptor) Input
10. USB Power Source (5V)
Input/extension
11. Front level control knob
12. Rear level control knob
13. Center level control knob
14. Vibration (subwoofer 5.1 channel) level
control knob
In-line Controller
