Teac PowerMax-HP10 - Connecting CD Players

36 | PowerMax-HP10
3. Connecting CD players
An external DC power supply is required. Connect the 7.5V DC
power supply to the 7.5V DC input jack on the back of the 5.1
amplifier box.
CD devices can be connected to the input AUX with the PC
connecting cable.
For power and signal connection method, please refer to the
picture below.
7.5V DC
Power Supply
PC connecting
cable (A)
CD
Back plate
PowerMax-HP10
