26 44 1705 001GB-H FMT 3 meter
"Reset" key: Switches between the characteristic curves for watery media (H2O) and for thin
mineral oils (dSL).
"Mode" key: Confirms the fluid shown and switches to
Calibration
.
5.4 Setting the calibration factor
5.4.1 Calibration
The selected characteristic curve of the FMT 3 can be subjected to an additional calibration to
compensate for special operating conditions, such as unusual media temperatures or borderline flow
values.
Shown on the partial volume display are the measured quantity for the last dispensation, as well as
the calibration factor in the lower line (factory default 1000, configurable values 500–1500).
"Reset" key: Increases calibration factor by 1; increases the dispensation value shown by
1/1000. Hold the key to increase the setting speed.
L
