4.4.1 Operationalgorithmselection
Accesstothissubmenuissecuredwithapassword.
FITTER'S
MENU



OPERATION
ALGORITHM
SELECTION


Standardoperation
 Automaticoperation

PID
Thisfunctionisusedtoselectoperationalgorithm.Dependingonselectedmode,theCHboileroperation
phaseswillchange.
 4.2Controlleroperationphases,page:10
4.4.2 Fire‐upparameters
FITTER'SMENU



FIRE‐UP
PARAMETERS


Blow‐bytime

Initialfeedingtime

Fanspeed

Maxheateroperationtime
Fire‐upparametersconcerndetailedfire‐upsettings.Thesettingsshouldbeadjustedaccordingtothetype
offuelused.

Blow‐bytime
Thisfunctionisusedtoconfigureblow‐bytimeinFire‐upmode.
Initialfeedingtime
Thisparameterdefinesthetimeofthesecondfire‐upphase.Duringthisphasethefuelisfedtothefurnace.

Fanspeed
Thisfunctionisusedtoconfigurefanspeedinthethirdfire‐upphase.Intheremainingphasesthespeedis
adjustedbythecontroller.

Maxheateroperationtime
Thisparameterconcernsthethirdphaseofthefire‐upprocess.Duringthisstage,theheater(igniter)isenabled
andremainsactiveuntilthesensordetectsfire.Iftheflamefailstoappearforalongtime,theigniterisdisabled
andthefuelfeedingisactivatedagain(lastinghalfofthetimesetbytheuserinInitialfuelfeedingtime).Next,
theheaterisenabledagain.Ifthesensordetectsfire,thecontrollerswitchestothelastphase‐Stabilization.
Ifthefiredoesnotappearafterthesecondfire‐upattempt,aftertheheaterprotectiontimethefire‐upprocess
willbestoppedandthedisplaywillinformaboutfire‐upfailure.
