4.4.15 Ethernetmodule
NOTE
Thistypeofcontrolisavailableonlyafterpurchasingandconnectinganadditionalcontrolling
moduleST‐505whichisnotincludedinthestandardcontrollerset.
FITTER'SMENU


ETHERNETMODULE


ModuleON

Registration

DHCP
 IPAddress
 IPMask
 Gateaddress
 DNSaddress

MACaddress

Moduleversion

ModuleOFF

 Beforeregisteringthemodule,itisnecessarytocreateuser’saccountonemodul.pl(ifyoudonot
haveone).

 Oncethemodulehasbeenconnectedproperly,selectModuleON.
 NextselectRegistration.Thecontrollerwillgenerateacode.
 Logonemodul.pl,gotoSettingstabandenterthecodewhichappearedonthecontrollerscreen.
