Tech Controllers ST-976 - Damping Parameters; Internal Feeder Coefficient; Exhaust Fan


26
4.4.3 Dampingparameters
FITTER'S
MENU


DAMPING
PARAMETERS


Fuelburnouttime

Dampingprotection

Fandampinggear

Dampingparametersconcerncontrollersettingsindampingmode. 
Fuelburnouttime
Thisparameterdefinesthedurationtimeofthelastdampingphase.Inthisphasethefanoperatesat
maximumspeed.Theaimofthisphaseistocleanthefurnace.
Dampingprotection
Thisparameterdefinesthedurationtimeofthefirstdampingphase.Inthisphasethefeederisdisabledand
thefanoperatesatauser‐definedspeed.Theaimofthisphaseistoburntheremainingfuel.
Fandampinggear
Thisfunctionisusedtoconfiguretheblowforceofthefansforthefirstdampingphase.

4.4.4 Internalfeedercoefficient
Thisvaluedefineshowmuchlonger(%)theinternalfanwilloperateincomparisontotheexternalfan.
4.4.5 Exhaustfan
FITTER'S
MENU 

EXHAUSTFAN


Fanworkingminimum

Fanworkingmaximum
NOTE
ThecontrollermayoptionallybeequippedwithanadditionalmoduleSWW‐1usingRS
communication.

Theaimoftheadditionaldeviceistoimprovethechimneydraught.Thedeviceiscontrolledbytheadditional
moduleSWW‐1usingRScommunication.Itadjustsitsrotationalspeedtotheburnerpower.Thefanoperates
inallCHboileroperationmodes,i.e.Fire‐up,OperationandDamping.
Fanworkingminimum
Theminimumexhaustfanspeedfortheminimumburnerpower.
Fanworkingmaximum
Themaximumexhaustfanspeedforthemaximumburnerpower.
NOTE
TheworkingrangeofMaximummaynotbelowerthantheMinimum.Oncethemodulehasbeen
connected,therangeupdatemaytakeafewminutes.
