30
Weather‐basedcontrol
BUILT‐IN
VALVE/
ADDITIONAL
VALVE1,2 

WEATHER‐
BASEDCONTROL



OFF

ON

Heatingcurve
For the function of weather control to be active, the external sensor mustn't be exposed to sunlight or
influencedbyweatherconditions.Afterithasbeeninstalledandconnected,weather‐basedcontrolfunction
needstobeactivatedinthecontrollermenu.
Heatingcurve
Heatingcurve–acurveaccordingtowhichthepre‐setcontrollertemperatureisdetermined,onthebasisof
externaltemperature.Inorderforthevalvetooperateproperly,theuserdefinesthepre‐settemperature
value(downstreamofthevalve)forrespectivevaluesofexternaltemperatures‐20°C,‐10°C,0°Cand10°C.
Howtoprogramtheheatingcurve:
 SelectHeatingcurveoption.


 Usetheicons  toselecttheexternaltemperaturethreshold.
 Definethepre‐settemperatureforagiventhresholdusingtheicons:  .
 Onceallvalueshavebeenconfigured,select .
Roomregulator
BUILT‐IN
VALVE/
ADDITIONAL
VALVE1,2 

ROOMREGULATOR


Controlwithoutroomregulator

Standardregulator

RSregulator‐proportional

Standardvalveregulator

Roomregtemplower

Valveclosing

Roomtemperaturedifference

Changeinthesettemp

Thisfunctionenablestheusertoselectandconfiguretheoperationoftheroomregulatorwhichwillcontrol
thevalve.
