33
Maximumtemperature
TheuserdefinestheminimumacceptableCHtemperatureatwhichthevalvewillclose.
Returnprotection
BUILT‐IN
VALVE/
ADDITIONAL
VALVE1,2 

RETURN
PROTECTION


OFF

ON

Minimumreturntemperature

ThisfunctionallowssettingupCHboilerprotectionagainsttoocoolwaterreturningfromthemaincirculation,
whichcouldcauselow‐temperatureboilercorrosion.Thereturnprotectioninvolvesclosingthevalvewhen
thetemperatureistoolow,untiltheshortcirculationoftheboilerreachestheappropriatetemperature.
Minimumreturntemperature
Theuserdefinestheminimumacceptablereturntemperatureatwhichthevalvewillclose.
Valvepump
BUILT‐IN
VALVE/
ADDITIONAL
VALVE1,2 

VALVEPUMP



AlwaysON

AlwaysOFF

ONabovethreshold

Pumpswitchontemperature

Thisoptionenablestheusertoselectthepumpoperationmode:
o AlwaysON‐thepumpoperatesallthetime,regardlessoftemperatures.
o AlwaysOFF‐thepumpispermanentlydeactivatedandtheregulatorcontrolsonlyvalveoperation
o ONabovethreshold‐thepumpisactivatedabovethepre‐setswitch‐ontemperature.Ifthepump
istobeactivatedabovethethreshold,theusershouldalsodefinethepumpswitchontemperature.
ThetemperatureisreadfromCHsensor.
Factorysettings
Thisfunctionenablestheusertorestorethefactorysettingsforaparticularvalve.Restoringfactorysettings
doesnotchangethetypeofvalveselected(CHorfloor).
Valveremoval
NOTE
Thisoptionisavailableonlyforanadditionalvalve(usinganexternalmodule).
Thisoptionisusedtoremovethevalvefromthecontrollermemory. Valve removal is used e.g. at
disassemblingthevalveormodulereplacement(re‐registrationofanewmoduleisnecessary).
