Sensor1selection
Thisoption isusedto selectwhich temperature sensorshould beused to providedata forcontrollingthe
operationofthedeviceconnectedtotheadditionalcontact–theheatsource(activationthreshold).
Sensor2selection
Thisoption isusedto selectwhich temperature sensorshould beused to providedata forcontrollingthe
operationofthedeviceconnectedtotheadditionalcontact–(pre‐settemperature).
Circulatingpump
TYPEOF
DEVICE 

CIRCULATING
PUMP



Operationtime

Pausetime

Operationschedule

Whenthisfunctionisactive,theadditionalpumpservesasthecirculatingpump.Thepumpcontrolsthevale
whichmixesthehotwaterbetweentheCHboilerandtheDHWreceivers.Thefollowingparametersneedto
beconfiguredforthecirculatingpumptoworkcorrectly:
Operationtime
Thisparametersdefinesthetimeofpumpoperationduringitsactivity.
Pausetime
Thisparameterdefinestheperiodoftimebetweencirculatingpumpactivations‐theperiodoftimewhenthe
pumpremainsinactive.
Operationschedule
Theusermayprogramadailyscheduleofpumpoperationandinactivity,withtheaccuracyof30minutes.The
pumpwillbeenabledatthefrequencydefinedinPausetimeparameteranditwillremainactiveforthetime
definedasOperationtime.
Toconfiguretheoperationschedule,followthesamestepsasforCHboileroperationschedule:
 4.3.6.1CHboileroperationschedule,page:17
Floorpump
TYPEOF
DEVICE 

FLOORPUMP



Roomregulator

Temperaturethreshold

Maximumtemperature

Sensor1selection

Sensor2selection

