22
nd
October 2004 SC2000 Manual – 177/52301 Rev G Page 3
1 INTRODUCTION
1.1 The SC2000 range of Controllers use a powerful microprocessor to control two power frames
- Traction (with regen or plug braking) and Pump. Both power frames are integrated within
one compact enclosure and use state-of-the-art mosfet technology.
The SC2000 is available in a wide range of voltage/current variants and power-frame
configurations. As well as the Traction + Pump controllers, the two power-frames within the
unit can also be configured as a Traction Dual Motor non - proportional + Pump controller or
as a Traction + Traction proportional unit. In addition standalone Traction or standalone
Pump units can be offered.
1.2 The controllers have been designed to satisfy the requirements of the relevant UL and EC
standards.
1.3 The controllers have been optimised for use with D.C. series wound motors. For other motor
types contact SEVCON.
