October 2004 SC2000 Manual – 177/52301 Rev G Page 43
Accelerator Characteristics
0
20
40
60
80
100
0 10 20 30 40 50 60 70 80 90 100
Linear Curved 2 Slope Crawl
Thermal Cutback Characteristic
0
20
40
60
80
100
% of Maximum Current
75 80 85 90 95
Controller Internal Temperature
( Deg C )
Safe Operating Area Graphs
