Page 4 SC2000 Manual – 177/52301 Rev G 22
nd
October 2004
2 SC2000 CONTROLLER VARIENTS
SCxxxx Model number description
1st digit Controller range identification (always 2)
2nd digit Controller 1 = Traction+Pump
Type 2 = Traction
3 = Pump
4 = Traction+Pump Dual Motor Non Proportional
5 = Traction+Traction Dual Motor Proportional
6 = Traction Dual Motor Non Proportional
3rd digit Voltage 2 = 24V - 36V
Range 4 = 24V - 48V
8 = 72V - 80V
9 = 72V - 96V
4th digit Current 2 = 250A Width = 230mm
Limit 5 = 500A Height = 113mm
6 = 650A
1 = 1000A
MODEL POWER CONFIGURATION
# Power
Terminals
UNIT
Length
SC2126 24-36V 2x650A Traction + Pump 7 424mm (D)
SC2145 24-48V 2x500A Traction + Pump 7 360mm (C)
SC2445 “ Traction Dual Motor Non Proportional + Pump 9 424mm (D)
SC2545 “ Traction + Traction Dual Motor Proportional 8 360mm (C)
SC2542 24-48V 2x250A Traction + Traction Dual Motor Proportional 8 360mm (C)
SC2146 24-48V 2x650A Traction + Pump 7 424mm (D)
SC2446 “ Traction Dual Motor Non Proportional + Pump 9 488mm (E)
SC2185 72-80V 2x500A Traction + Pump 7 488mm (E)
SC2485 “ Traction Dual Motor Non Proportional + Pump 9 552mm (F)
SC2585 “ Traction + Traction Dual Motor Proportional 8 488mm (E)
SC2186 72-80V 2x650A Traction + Pump 7 552mm (F)
SC2586 “ Traction + Traction Dual Motor Proportional 8 552mm (F)
SC2286 72-80V 1x650A Traction 5 360mm (C)
SC2386 “ Pump 4 360mm (C)
SC2296 72-96V 1x650A Traction 5 360mm (C)
SC2396 “ Pump 4 360mm (C)
SC2291 72-96V1x1000A Traction 5 488mm (E)
