Page 34 SC2000 Manual – 177/52301 Rev G 22
nd
October
2004
11.1.2 STANDARD DISPLAY TECHNICAL SPECIFICATIONS
11.1.2.1 Environmental
Protection (front face): IP65
Protection (rear): IP34
Vibration: 6G, 0-150Hz for 1 hour
Operating Temperature: -5
o
C to +50
o
C
Storage Temperature: -40
o
C to +85
o
C
Humidity: 95% maximum, non-condensing
Humidity Resistance: No functional defects after display is left at 60
o
C and 100%
humidity for one hour after freezer use (-30
o
C minimum).
11.1.2.2 Mechanical
Mounting Hole: 2” Nominal. (See mechanical drawing)
Unit weight: 0.12 Kg (including mounting bracket)
Enclosure: Injection moulded plastic case, with transparent front facia.
Connections: One 6 way AT socket.
Fixings method: Mounting bracket supplied
11.1.3 Electrical
Power Supply: Derived from CANbus
Supply Current 60mA (typical)
