Page 52 SC2000 Manual – 177/52301 Rev G 22
nd
October
2004
Mechanical Dimensions - Traction and Pump
40 40
7 7
2
1
6
2
3
0
SC2145 360MM ("X"=180MM)
SC2126 424MM ("X"=212MM)
SC2146 424MM ("X"=212MM)
CALIBRATOR CONNECTOR
PANEL CONNECTO
R
USER CONNECTOR
93
60.2
113
"X"
7
SC2185 488MM ("X"=244MM)
SC2186 552MM ("X"=276MM)
