5 Configuration
The BRSPY mini is configured by 8 DIP Switches on the front of the device.
DIP Switch 1: ON = BroadR-Reach Port 1A is set to Master Port 1B to slave.
OFF = BroadR-Reach Port 1B is set to Master Port 1A to slave.
DIP Switch 2: ON = BroadR-Reach Port 2A is set to Master Port 2B to slave.
OFF = BroadR-Reach Port 2B is set to Master Port 2A to slave.
DIP Switch 3 to 4: Use Case Selection. Binary Coded from 00 to 11.
Please refer chapter “Use Cases” in this User manual for further
information.
DIP Switch 5 to 8: Frame Generator speed, burst and packet size selection
