1 Feature List
The Technica Engineering BR SPY mini samples BroadR-Reach Frames directly on the bus
without influence of the original network. The data Frames are enhanced with additional in-
formation as an exact timestamp and the bus port the data was originally sent on. All data
can be recorded on a PC or datalogger for detailed offline analysis.
Timestamps are in 0.04 μs resolution and synchronous to all connected lines.
Optionally other UseCases (Frame Generator, Trigger Generator, …) can be upgraded.
Features:
• 4 Ports BroadR-Reach Ethernet 100 MBit/s Fullduplex on a single unshielded twisted
pair.
• 2 Ports Gigabit Ethernet 100/1000 BaseTX
• 6x Digital Trigger Input
• 6x Digital Trigger Output
• Automotive Tyco MQS Connectors for BroadR-Reach and Power Supply
• Robust steel case
• DIP Switches for easy configuration
• Selection of multiple UseCases:
o Two independent MediaConverters
o 2x SPY for listening on a BroadR-Reach Channel
Power requirement: 8 to 16 Volt DC (nominal 12 Volt DC)
Power consumption: 4 to 7 Watt
Size: 110 x 108 x 28 mm
Weight: 0,4 kg
International Protection: IP 2 0
Operating Temperature: -20 to +80 °Celsius
