7 Trigger Functions
The Trigger Output signals detect when a frame is received in one of the BroadR-Reach
ports -when detects the Data Valid rising edge-, and when a frame is being transmitted on
one of the Gigabit ports, as is shown in the following table:
Pin
Function
1
BR1A Data Valid
2
BR1B Data Valid
3
Signal Ground Reference
4
Signal Ground Reference
5
Signal Ground Reference
6
BR2A Data Valid
7
BR2B Data Valid
8
GB1 Data Enable
9
GB2 Data Enable
