The following table defines the content of the Status Frame Data. These fields are replicated
four times, one per BroadR-Reach port, giving information about the communication status in
every single port.
Field
Size
(bytes)
Description
SequenceCounterLocked
2
Lowest Bit shows if the Sequence Counter Checker found at least
one valid pair and then was enabled. It is disabled while errors
occur.
SequenceErrorCounter
2
Counter for detected sequence errors after checker locked. This
counter is not reset.
IgnoredFrameCounter
2
Counter for frames, that were not in the right format to be
checked.
CRC_ErrorCounter
2
Counter for CRC errors in all received frames
ReceivedFrameCounter
2
Total of all received frames including malformed frames
MeasuredFramesPerSecond
2
Received Frames per second with valid preamble.
MeasuredBitsPerSecond
2
RX_DV High Time vs. Low Time
[MBits/s]
