3.2 SubD 9 Trigger Connector
Standard SubD 9 Pos. female connector.
This connector is used for digital input and output trigger functions.
Pin
Function
1
Digital Trigger Input/Output 1
2
Digital Trigger Input/Output 2
3
Signal Ground Reference
4
Signal Ground Reference
5
Signal Ground Reference
6
Digital Trigger Input/Output 3
7
Digital Trigger Input/Output 4
8
Digital Trigger Input/Output 5
9
Digital Trigger Input/Output 6
Digital Trigger Output:
Digital Trigger Output Voltage is 3.3 Volt Level with a 4.7 KOhm Pull-up resistor.
Active LOW. Drive Strength 20 mA.
Digital Trigger Input:
Digital Trigger Voltage is 3.3 Volt Level with a 4.7 KOhm Pull-up resistor.
Active LOW
3.3 RJ45 Ethernet connectors
There are two RJ45 Standard Ethernet connectors of the front side for Gigabit Ethernet.
Depending on the selected Use Case they are forced to be 100 Mbit/s or Gigabit Ports.
