3.1 Power and BroadR-Reach connector
Connector color: Black
Power supply for the device is supplied by Pin 1 (12 Volt) and Pin 10 (Ground).
Warning: If you apply a voltage higher than 18 Volt, the device will be damaged!
The Tyco Electronics (TE) Micro Quad Lock System (MQS) is used.
Tyco, MQS Abdeckkappe, 2x9 Pol, black Part Number 1-967416-1
alternatively Part Number 1-1355350-1
Tyco, MQS Buchsengehäuse, 2x9 Pol Part Number 965778-1
alternatively Part Number 962108-2
Tyco crimp contact Part Number 928999-1
Note: You can use the official Tyco tool for these crimp contacts. A cheap variant is the
crimp tool for “PSK” contacts.
Pin
Function
Pin
Function
1
Battery +12 Volt Input
10
Power Ground
2
n.c.
11
n.c.
3
n.c.
12
n.c.
4
n.c.
13
n.c.
5
BroadR-Reach Port 1A, Negative
14
BroadR-Reach Port 1B, Negative
6
BroadR-Reach Port 1A , Positive
15
BroadR-Reach Port 1B , Positive
7
n.c.
16
n.c.
8
BroadR-Reach Port 2A, Negative
17
BroadR-Reach Port 2B, Negative
9
BroadR-Reach Port 2A , Positive
18
BroadR-Reach Port 2B , Positive
