Technicolor MediaAccess TG788VN User Manual

26
3 MANUAL INSTAL
LATION
DMS-CTC-20120510-0000 v1.0
3.4 Configure the MediaAccess Gateway
Introduction
If your service provider did not preconfigure your MediaAccess Gateway, you may have to configure the MediaAccess
Gateway via its Graphical User Interface (GUI).
Requirements
JavaScript must be enabled on your web browser (this is the default setting). For more information, consult the help of your
web browser.
Procedure
Proceed as follows:
1 Open your web browser.
2 The MediaAccess Gateway informs you that you have not yet configured your MediaAccess Gateway.
If this window does not appear, browse to http://dsldevice.lan
or to the IP address of your MediaAccess Gateway (by
default: 192.168.1.254
) and click Technicolor Gateway on the menu on the left-hand side.
3 Click Setup my Technicolor Gateway.
4 The Easy Setup wizard appears. This wizard will guide you through the configuration of your MediaAccess Gateway.
Click Next and follow the instructions.

Technicolor MediaAccess TG788VN Specifications

General

Wi-Fi Frequency Bands	2.4 GHz
Wireless Speed	Up to 300 Mbps
Ethernet Ports	4 x 10/100 Mbps
VoIP	Yes
Wireless Standard	802.11b/g/n
USB Ports	1 x USB 2.0
DSL Interface	RJ11
ADSL Standards	ITU-T G.992.1 (G.dmt) Annex A, ITU-T G.992.2 (G.lite) Annex A
ADSL2 Standards	ITU-T G.992.3 (G.dmt.bis) Annex A, Annex L, Annex M
ADSL2+ Standards	ITU-T G.992.5 (ADSL2+)
Security	WEP, WPA, WPA2
Power Supply	12V DC, 1.5A
VPN	IPSec
