Technicolor MediaAccess TG788VN User Manual

34
4CONFIGURATIO
N TOOLS
DMS-CTC-20120510-0000 v1.0
4.1.2 Components
Overview
Depending on your user right and location on the GUI, the following components can be available:
Menu
The menu consists of the following menu items:
 Home:
Allows you to go back to the MediaAccess Gateway home page.
 Technicolor Gateway:
Provides basic information on the MediaAccess Gateway.
 Broadband Connection:
Allows you to view/configure your broadband connections.
 To o l b o x :
Allows you to configure the network services and security settings of your MediaAccess Gateway.
 Home Network:
Allows you to manage your local network.
 Help:
Allows you to view context-related help information.
Each of these items contain a number of sub-menu items.
Label Description
1 Menu
2 Login section
3 Language bar
4 Notification area
5 Navigation bar
6 Content pane
7 Tasks pane
4
5
1
3
6
7
2

Technicolor MediaAccess TG788VN Specifications

General

Wi-Fi Frequency Bands	2.4 GHz
Wireless Speed	Up to 300 Mbps
Ethernet Ports	4 x 10/100 Mbps
VoIP	Yes
Wireless Standard	802.11b/g/n
USB Ports	1 x USB 2.0
DSL Interface	RJ11
ADSL Standards	ITU-T G.992.1 (G.dmt) Annex A, ITU-T G.992.2 (G.lite) Annex A
ADSL2 Standards	ITU-T G.992.3 (G.dmt.bis) Annex A, Annex L, Annex M
ADSL2+ Standards	ITU-T G.992.5 (ADSL2+)
Security	WEP, WPA, WPA2
Power Supply	12V DC, 1.5A
VPN	IPSec
