Technicolor MediaAccess TG788VN User Manual

53
6 TELEPHONY
DMS-CTC-20120510-0000 v1.0
6.3 Telephony Services
Introduction
Telephony services add extra functionality to your phone. For example: putting a call on hold, transferring calls,...
Requirements
Before you can use a service, must both be:
1 Supported by your service provider.
2 Activated on your MediaAccess Gateway.
Checking if a telephone service is activated/supported
To check which services are supported or activated, proceed as follows:
1 Browse to the MediaAccess Gateway GUI.
For more information, see “4.1 MediaAccess Gateway GUI” on page 32.
2 On the Toolbox menu, click Te l e p h o n y.
3 In the Navigation bar, click Configure.
4 In the Pick a task list, click View Telephony Services.
5 Under Te l e p h o n y S e r v i ce s, you can see the services that are supported by your provider.
In the Activated column, you can see if this service is also activated on the MediaAccess Gateway.
6 To (de)activate a service, proceed with “6.3.1 Activating a Telephony Service on your MediaAccess Gateway” on page 54.

Technicolor MediaAccess TG788VN Specifications

General

Wi-Fi Frequency Bands	2.4 GHz
Wireless Speed	Up to 300 Mbps
Ethernet Ports	4 x 10/100 Mbps
VoIP	Yes
Wireless Standard	802.11b/g/n
USB Ports	1 x USB 2.0
DSL Interface	RJ11
ADSL Standards	ITU-T G.992.1 (G.dmt) Annex A, ITU-T G.992.2 (G.lite) Annex A
ADSL2 Standards	ITU-T G.992.3 (G.dmt.bis) Annex A, Annex L, Annex M
ADSL2+ Standards	ITU-T G.992.5 (ADSL2+)
Security	WEP, WPA, WPA2
Power Supply	12V DC, 1.5A
VPN	IPSec
