Technicolor MediaAccess TG788VN User Manual

22
3 MANUAL INSTAL
LATION
DMS-CTC-20120510-0000 v1.0
3.2 Powering on the MediaAccess Gateway
Procedure
Proceed as follows:
1 Connect the power cord to the power port of the MediaAccess Gateway.
2 Plug the other end of the power cord into an electrical outlet.
3 Press the power button to turn on the MediaAccess Gateway.
4 Wait at least two minutes to allow the MediaAccess Gateway to complete the start up phase.

Technicolor MediaAccess TG788VN Specifications

General

Wi-Fi Frequency Bands	2.4 GHz
Wireless Speed	Up to 300 Mbps
Ethernet Ports	4 x 10/100 Mbps
VoIP	Yes
Wireless Standard	802.11b/g/n
USB Ports	1 x USB 2.0
DSL Interface	RJ11
ADSL Standards	ITU-T G.992.1 (G.dmt) Annex A, ITU-T G.992.2 (G.lite) Annex A
ADSL2 Standards	ITU-T G.992.3 (G.dmt.bis) Annex A, Annex L, Annex M
ADSL2+ Standards	ITU-T G.992.5 (ADSL2+)
Security	WEP, WPA, WPA2
Power Supply	12V DC, 1.5A
VPN	IPSec
