20
Connections
AC mains lead
AC mains lead connection
Connect only after all other connections are
completed.
10BASE
-
T/
100BASE
-
TX
OPT INLAN AUX IN
DIMMER
INFO
AC IN
500mA5V
To a household mains
socket
• Use only the supplied AC mains lead.
• Do not connect the AC mains lead until all other
connections are complete.
• Insert the plugs of the cables to be connected all
the way in.
• Do not bend cables at sharp angles.
• Wireless LAN (Wi-Fi
®
) setting may start when this
unit is turned on. If you stop the Wi-Fi setting,
press [ ]. To keep the Wi-Fi setting, start the
“Google Home” app and follow the on-screen
instructions. (⇒ 21, 23)
Note
• This unit consumes a small amount of AC power
(⇒ 65) even when the unit is in standby mode.
Remove the plug from the main electrical outlet
if you will not be using the unit for an extended
period of time. Place the unit so the plug can be
easily removed.
To Next Page
