Technics SA-310 Service Manual

SA-EX310
Ref No. Part No. Part Name & Description Remarks
Ref No. Part No. Part Name & Description Remarks Ref No. Part No. Part Name & Description Remarks
D705 MTZJ6R2BTA DIODE [ M ]
D707 MTZJ27DTA DIODE [ M ]
D708 MTZJ15CTA DIODE [ M ]
D721 1N5402BM21 DIODE [M ]
D722 1N5402BM21 DIODE [M ]
D723 1N5402BM21 DIODE [M ]
D724 1N5402BM21 DIODE [M ]
D731 MTZJ24DTA DIODE [ M ]
D732 RVD1SS133TA DIODE [ M ]
D733 RVD1SS133TA DIODE [ M ]
D751 1SR35200TB DIODE [ M ]
D752 1SR35200TB DIODE [ M ]
D753 1SR35200TB DIODE [ M ]
D754 1SR35200TB DIODE [ M ]
D755 RVD1SS133TA DIODE [ M ]
D756 MTZJ6R8BTA DIODE [ M ]
D771 RVD1SS133TA DIODE [ M ]
D772 RVD1SS133TA DIODE [ M ]
D773 MTZJ9R1CTA DIODE [ M ]
D775 RVD1SS133TA DIODE [ M ]
D781 RVD1SS133TA DIODE [ M ]
D782 RVD1SS133TA DIODE [ M ]
D901 1SS291TA DIODE [M ]
D903 MTZJ4R7BTA DIODE [ M ]
D921 RVD1SS133TA DIODE [ M ]
D923 RVD1SS133TA DIODE [ M ]
D924 MTZJ3R9ATA DIODE [ M ]
D925 RVD1SS133TA DIODE [ M ]
D929 LN846RPH DIODE [ M ]
D1001 MTZJ10CTA DIODE [ M ]
VARIABLE RESISTORS
VR501 EUWMRH026B15 VR, MOTOR [M]
VR502 EVJ02QF01G15 VR, BALANCE CONTROL [M]
VR511 EVJYA1F01C15 VR, TONE CONTROL [M]
VR512 EVJYA1F01C15 VR, TONE CONTROL [M]
SWITCHES
S946 EVQ21405R SW , POWER [M ]
S947 EVQ21405R SW , PHONO [ M]
S948 EVQ21405R S W, MUTING [M]
S950 EVQ21405R S W, FM MODE [M]
S951 EVQ21405R S W, BAND [M]
S952 EVQ21405R SW, TUNING DOWN [M ]
S953 EVQ21405R S W, TUNING UP [M]
S955 EVQ21405R S W, MEMORY [M]
S956 EVQ21405R S W, PRESET DOWN [M]
S957 EVQ21405R S W, PRESET UP [M]
S960 EVQ21405R S W, TUNER [M]
S961 EVQ21405R S W, CD [M]
S962 EVQ21405R S W , TAPE [M]
S963 EVQ21405R S W , TV/DVD [M]
S964 EVQ21405R S W, VCR [M]
S970 EVQ21405R S W, SEARCH [M]
S971 EVQ21405R S W, EON [M]
S972 EVQ21405R S W , PTY UP [M]
S973 EVQ21405R S W, PTY DOWN [M]
S974 EVQ21405R S W, D IS PL A Y M OD E [ M ]
S980 EVQ21405R S W , SPEAKERS [M]
S983 EVQ21405R S W, OFF/ON [M ]
S984 EVQ21405R SW, PRO-LOGIC [M]
S985 EVQ21405R S W, CENTER MODE [M]
CONNECTORS
CN101 RJU057W007 7P CONNECTOR [ M ]
CN102 RJU057W007 7P CONNECTOR [ M ]
CN401 RJU100W07 7P CONNECTOR [ M ]
CN402 RJU100W07 7P CONNECTOR [ M ]
CN501 RJU100W07 7P CONNECTOR [ M ]
CN502 RJU100W04 4P CONNECTOR [ M ]
CN701A RJS1A6604T1 4P TAPING CONNECTOR [M]
CN701B RJS1A6604T1 4P TAPING CONNECTOR [M]
CN701C RJS1A6604T1 4P TAPING CONNECTOR [M]
CN751 SJS305-1 3P CONNECTOR [ M ]
CN752 RJS1A6603T1 3 PIN TAPING CONNECT [M]
CN901 RJU003K008M1 BOAD IN CONNECTOR [M ]
CN902 RJU003K008M1 BOAD IN CONNECTOR [M ]
CN903 RJU003K008M1 BOAD IN CONNECTOR [M ]
CN904 RJU003K008M1 BOAD IN CONNECTOR [M ]
CN905 RJU003K008M1 BOAD IN CONNECTOR [M ]
CP101 RJT057W007-1 7P CONNECTOR [ M ]
CP102 RJT057W007-1 7P CONNECTOR [ M ]
CP401 RJT100W07 7 P CONNECTOR [ M ]
CP402 RJT100W07 7 P CONNECTOR [ M ]
CP501 RJT100W07 7 P CONNECTOR [ M ]
CP502 RJT100W04 4 P CONNECTOR [ M ]
CP771 RJP3G4YA CONNECTOR [ M ]
CP901 RJT003K008M1 8P CONNECTOR [ M ]
CP902 RJT003K008M1 8P CONNECTOR [ M ]
CP903 RJT003K008M1 8P CONNECTOR [ M ]
CP904 RJT003K008M1 8P CONNECTOR [ M ]
CP905 RJT003K008M1 8P CONNECTOR [ M ]
COILS & TRANSFORMERS
L101 EL ES N1 R0 MA C H O K E COIL [ M]
L103 EL EXTR47MA9 CHOKE COIL [ M]
L105 RL QZB 822KT-D TAPING COIL [M]
L106 RL QZB 822KT-D TAPING COIL [M]
L151 SL M 1 B1 0 - 1M A . B . F I L T E R [ M]
L191 ELESNR56MA CHOKE COIL [M]
L501 RL QZP 1R 0K T-Y AX I AL C O IL [ M ]
L502 RL QZP 1R 0K T-Y AX I AL C O IL [ M ]
L601 RLQ YR7 3MW -E C H O K E COIL [M]
L602 RLQ YR7 3MW -E C H O K E COIL [M]
L603 RLQ YR7 3MW -E C H O K E COIL [M]
L604 RLQ YR7 3MW -E C H O K E COIL [M]
L751 EL ESN101KA CHOKE COIL [M]
L791 SLQ Z650MH49 A C L I N E C O I L [ M ]
L901 RL QB 101KTA-Y CHO KE COIL [M]
L902 RL QZ P101KT-Y AXIAL COIL [M]
L1051 E LESN101KA CHOKE COIL [M]
T701 RTP1N5B025-X
POWER TRANSFORMER [M]
T751 RTP1I5E006
TRANSFORMER (SMALL) [M]
COMPONENT COMBINATION
Z101 RLA2Z002M-T A M ANT. COIL [M]
Z102 RLI2Z006M-T AM IFT [ M]
Z120 ENV17290G1R F M TUNER PACK [M]EG
Z120 ENV17290G1Y FM TUNER PACK [M]EB E
Z751 ERZV10V511CS ZNR[M]
Z891 RCDSPS4242N REMOTE SENSOR [M ]
CERAMIC FILTERS
CF201 RLFFETNGD01L CERAMIC FILTER [M]
CF202 RLFFETMGD01L CERAMIC FILTER [M]
CF901 RVBCST4R00MT CERAMIC OSCILLATOR [M]
CF902 RSXZ456KM07M CERAMIC OSCILLATOR [M ]
CF1051 EF 0EC8004T4 CERAMIC OSCILLATOR [ M]
OSCILLATORS
X101 RSXZ456KM07M CERAMIC OSCILLATOR [M]
X102 RLFDGTD01I FM REZONATOR [ M ]
X103 SVQ49U722T-S CERAMIC 7.2MHz [M]
DISPLAY TUBE
FL901 R SL0233-F FL[M]
EARTH TERMINALS
E401 SNE1004-2 EARTH TERMINAL [M]
E601 SNE1004-2 EARTH TERMINAL [M]
FUSES
F1 XBA2C20TB0 FUSE [ M ]
F3 XBA2C50TB0 FUSE [ M ]
