Technics SA-310 Service Manual

SA-EX310
Ref No. Part No. Part Name & Description Remarks Ref No. Part No. Part Name & Description Remarks Ref No. Part No. Part Name & Description Remarks
Replacement Parts List
Notes:* Important safety notice :
Components identified by
mark have special characteristics important for safety.
Furthermore, special parts which have purposes of fire-retardant (resistors), high-quality sound (capacitors), low-noise (resistors), etc. are used.
When replacing any of components, be sure to use only manufacturer's specified parts shown in the parts list.
* The parenthesized in the Remarks columns specify the areas. (Refer to the cover page for area.)
Parts without these indication can be used for all areas.
* [M] in Remarks column indicates parts that are supplied by MESA.
* Remote Control Unit : Supply period for three years from terminal of production.
* The "(SF)" mark denotes the standard part.
CABINET AND CHASSIS
1 REM0069 FAN UNIT [M]
2 RFKGEX310EK FRONT PANEL ASSY [M]
3 RGR0251B-A REAR PANEL [M]EG E
3 RGR0251B-B REAR PANEL [M]EB
4 RGU1350-K MODE BUTTON [M]
5 RGU1352M-K DOLBY BUTTON [M]
6 RGU1493-K SELECTOR BUTTON [M]
7 RGW0243A-K VOLUME KNOB [M]
8 RGW0244-K1 BASS TREBLE KNOB [M]
9 RHD26016 SCREW [M]
10 RHN90001 M9 NUT [M]
12 RKA0079-A LEG [M]
13 RKM0260D-K TOP CABINET [M]EG E
14 RKQ0089-J PCB HOLDER [M]
15 RKW0436E-Q FL WINDOW [M]
16 RMC0158-S TRANSISTOR HOLDER [M]
17 RMG0270-K LEG CUSHION [M]
18 RMK0350 BOTTOM CHASSIS [M]
19 RMN0372 FL HOLDER [M]
20 RMQ0709 TUNER PCB BRACKET [M]
21 RMZ0339 ZNR COVER [M]
22 RXX0186 HEAT SINK UNIT [M]
23 SJS9231A A/C INLET COVER [M]
24 SNE2123 EARTH TERMINAL [M]
25 SNE2129-1 SCREW (CABINET) [M]
26 XTB3+20JFZ SCREW [M]
27 XTB3+30J SCREW (FAN) [M]
28 XTB3+8FFZ SCREW [M]
29 XTBS26+10J SCREW (FRONT) [M]
30 XTBS3+8JFZ1 SCREW [M]
31 XTW3+15T SCREW [M]
INTEGRATED CIRCUITS
IC101 LA1832A IC, IF/MPX [M]
IC102 LC7218 IC, PLL [M]
IC351 NJM2279D IC, VIDEO SELECTOR [M]
IC401 TC9163AN IC, SELECTOR [M]
IC402 M5218AP IC, BUFFER AMP [M]
IC451 AN6558F IC, OP AMP [M]
IC501 BA6218 IC, MOTOR DRIVER [M]
IC511 UPC4570C IC, TONE CONTROL [M]
IC551 UPC4570C IC, TONE CONTROL [M]
IC601 RSN307M44-P IC, HIC [M]
IC901 M38B53M4053F IC, MICOM [M]
IC902 STK311-010 IC, RDS DECODER [M]
IC1001 LA2786L IC, DPL [M]
IC1002 LV1016L IC, SURR DECODER [M]
TRANSISTORS
Q101 2SC2787LTA TRANSISTOR [ M ]
Q103 2SC2785FETA TRANSISTOR [ M ]
Q104 2SC2785FETA TRANSISTOR [ M ]
Q106 RVTDTA143XST TRANSISTOR [ M ]
Q107 2SC3311ARTA TRANSISTOR [ M ]
Q108 2SC3311ARTA TRANSISTOR [ M ]
Q351 2SD592AQRSTA TRANSISTOR [ M ]
Q352 2SB621AQSTA TRANSISTOR [ M ]
Q505 2SD1915FTA TRANSISTOR [ M ]
Q506 2SD1915FTA TRANSISTOR [ M ]
Q561 2SD1915FTA TRANSISTOR [ M ]
Q562 2SD1915FTA TRANSISTOR [ M ]
Q601 2SC1740SSTA TRANSISTOR [ M ]
Q602 2SC1740SSTA TRANSISTOR [ M ]
Q603 2SC1740SSTA TRANSISTOR [ M ]
Q604 2SC1740SSTA TRANSISTOR [ M ]
Q605 RVTDTA113ZST TRANSISTOR [ M ]
Q606 RVTDTA113ZST TRANSISTOR [ M ]
Q608 2SD1915FTA TRANSISTOR [ M ]
Q681 2SD1915FTA TRANSISTOR [ M ]
Q682 2SD1915FTA TRANSISTOR [ M ]
Q701 2SD2374PQAU TRANSISTOR [ M ]
Q703 2SC1740SSTA TRANSISTOR [ M ]
Q704 2SC1740SSTA TRANSISTOR [ M ]
Q706 2SC3940AQSTA TRANSISTOR [ M ]
Q707 2SB621AQSTA TRANSISTOR [ M ]
Q708 2SB1548PQAU TRANSISTOR [ M ]
Q731 2SB1417PQTA TRANSISTOR [ M ]
Q732 2SC1740SSTA TRANSISTOR [ M ]
Q733 2SC1740SSTA TRANSISTOR [ M ]
Q734 2SD2137PQTA TRANSISTOR [ M ]
Q735 2SA992EFTA TRANSISTOR [ M ]
Q737 2SA992EFTA TRANSISTOR [ M ]
Q751 RVTDTC143XST TRANSISTOR [ M ]
Q752 2SC3940AQSTA TRANSISTOR [ M ]
Q771 2SA933SSTA TRANSISTOR [ M ]
Q772 2SC1740SSTA TRANSISTOR [ M ]
Q773 2SB621AQSTA TRANSISTOR [ M ]
Q774 RVTDTA114EST TRANSISTOR [ M ]
Q775 2SA933SSTA TRANSISTOR [ M ]
Q776 2SC1740SSTA TRANSISTOR [ M ]
Q777 2SA933SSTA TRANSISTOR [ M ]
Q778 RVTDTA114TST TRANSISTOR [ M ]
Q779 RVTDTA114TST TRANSISTOR [ M ]
Q901 RVTDTC114YST TRANSISTOR [ M ]
Q902 2SA933SSTA TRANSISTOR [ M ]
Q907 RVTDTC114YST TRANSISTOR [ M ]
Q909 2SC1740SSTA TRANSISTOR [ M ]
Q937 RVTDTA114YST TRANSISTOR [ M ]
Q1001 2SC3940AQSTA TRANSISTOR [ M ]
DIODES
D101 MTZJ5R1BTA DIODE [M ]
D102 MA165TA DIODE [ M ]
D351 MTZJ5R6BTA DIODE [M ]
D352 MTZJ5R6BTA DIODE [M ]
D401 MTZJ7R5CTA DIODE [ M ]
D601 SB360L6508 DIODE [ M ]
D602 SB360L6508 DIODE [ M ]
D605 RVD1SS133TA DIODE [ M ]
D606 RVD1SS133TA DIODE [ M ]
D608 MTZJ6R2BTA DIODE [ M ]
D701 1N5402BM21 DIODE [M ]
D702 1N5402BM21 DIODE [M ]
D703 1N5402BM21 DIODE [M ]
D704 1N5402BM21 DIODE [M ]
