Technics SC-EH560

Basic operations
RQT5355
18
2
1
3
4
5
5 H/I
324 11
DECK 1/2
@
DECK 1/2
E OPEN
DOLBY NR
REV MODE
VOLUME
UP
DOWN
A
Î NR
1
ÎNR1
ÎNR
2
Cassette tapes
Preparation: Press [ê/I] to turn the unit on.
1 Press [< OPEN] on deck 1 or deck 2
and insert the cassette.
2 Press [DOLBY NR] to select Dolby NR
on
(“ëNR” appears) or off.
(➡ “Dolby noise reduction” page 19)
3 Press [REV MODE] to select the re-
verse mode.
Each time you press the button:
h: One side is played.
d: Both sides are played.
f: Both sides are played 8 times each.
4 Press ["] (reverse side) or [!] (forward side).
Play begins and the indicator changes to green.
5 Adjust the volume.
To stop the tape
Press [º].
[A] To change the deck to be used
Press [DECK 1/2] to select the deck you want to play.
To listen to 2 tapes consecutively
Insert a tape into each deck and select “f”. Both tapes will be
played 8 times each.
Cassette tape selection and care
The unit can correctly play the following types. It identifies the type
automatically.
³Tapes exceeding 100 minutes are thin and can break or get caught
in the mechanism.
³Tape slack can get caught up in the mechanism and should be tak-
en up before the tape is played.
³Endless tapes can get caught up in the deck’s moving parts if used
incorrectly. Use tapes appropriate to this unit’s auto-reverse mech-
anism.
Normal position/TYPE I ✔
High position/TYPE II ✔
Metal position/TYPE IV ✔
Forward side
Tape facing down
Tape direction
Deck in use
