Technics SJ-HD501

Pin
No.
Mark I/O
Division
Function
57 SGSYNC O Frame synchronous signal
output terminal
58 DVDD1 I Power supply terminal
59 IVDD1 — Power supply terminal for
I/O pad
60 DVss1 — GND terminal
61 FS384 O 384 Fs output terminal
62 SCL O Bit clock output terminal
63 SWS O Word clock output terminal
64 SDAP O Audio data output terminal
65 SDAR I Audio data input terminal
66 LRCK I CD word clock input
terminal (Connected to
GND)
67 BCK I CD bit clock input terminal
(Connected to GND)
68 DATA I CD data input terminal
(Connected to GND)
69 TX O Digital audio interface
signal output terminal (Not
used, open)
70 RX1 I Digital audio interface
signal 1 input terminal
71 RX2 I Digital audio interface
signal 2 input terminal
72 NREFM — EFM modulation inverted
output (Not used, open)
73 REFM O EFM modulation output
terminal
74 MONI3 — Monitor signal output (Not
used, open)
75 MONI2 — Monitor signal output (Not
used, open)
76 MONI1 — Monitor signal output (Not
used, open)
77 MONI0 — Monitor signal output (Not
used, open)
78 TS3 — Not used, connected to
GND
79 TS2 — Not used, connected to
GND
80 TS1 — Not used, connected to
GND
81 TS0 — Not used, connected to
GND
43
