Technics SL-1200GR2 User Manual

Putting the player together
12
Connecting to the PHONO terminals and AC IN terminal
Make connection to the PHONO terminals and AC IN terminal before setting up or installing
the player.
1
Take out the player from the package, and rest the player in the assembled
cardboard box so that you can make connection to the PHONO terminals
and AC IN terminal on the back side.
2
Connect the supplied PHONO cable, PHONO earth lead, and AC mains lead.
Be careful not to tip over the player.
Attention
To avoid damaging the player,
cover the player contact area
with a soft cloth or a protection
sheet wrapping the player.
②
Fold the pad along the creases on the back side.
③
Put the pad into
cardboard box.
⑤
Rest the player in the box.
Connecting the PHONO earth lead to
the player and amplifier.
(Black)
(White)
(Red)
Insert the AC mains lead
up to a point just before
the round hole.
④
Fold the front flap inside.
Proceed to
2
.
Pad


Turn the terminal to the left
to loosen.

Insert the earth lug and
tighten the terminal
securely.
Point the vertex of
▷
at the
short side of the cardboard box.
①
Take out the pad in the
bottom
.
SL-1200GR2EBTQBM0908.indd13SL-1200GR2EBTQBM0908.indd13 2023/06/3013:10:382023/06/3013:10:38

Technics SL-1200GR2 Specifications

General

Drive Method	Direct Drive
Motor	Coreless Direct Drive Motor
Effective Tonearm Length	230 mm
Overhang	15 mm
Tracking Force Adjustment Range	0 - 4 g (Direct Reading)
Power Consumption	11 W
Dimensions (W x H x D)	453 x 173 x 372 mm
Power Supply	AC120 V, 60 Hz
Turntable Platter	Aluminum Die-cast
Speeds	33-1/3 rpm, 45 rpm, 78 rpm
Wow and Flutter	0.025% W.R.M.S.
Tonearm Type	Universal Static Balance
Headshell Weight	7.6 g
Applicable Cartridge Weight Range (without auxiliary weight)	5.6 - 12.0 g
Weight	11.5 kg
Signal-to-Noise Ratio	78 dB
Terminals	PHONO x 1, GND x 1
