Technics SL-1200GR2 User Manual

Connecting to an integrated amplifier or component system
Connections and installation

Turn off all units and disconnect the AC mains lead from the socket before making any
connections.

Connect the AC mains lead only after all other connections are completed.

Be sure to connect the PHONO earth lead. Otherwise mains hum may occur.

Refer also to the instruction manual of the connected device.
1
Connect the PHONO cable and
PHONO earth lead to the PHONO
input terminals of the connected
equipment.

You will not have adequate volume or
sound quality if the connected amplifier
has no PHONO input terminals.
2
Connect the AC mains lead.

Confirm the wattage of the AC outlet on
the connected equipment before using it
for this unit.
(This unit consumes 11 W.)

The operation switch does not separate entire unit from mains even if in “OFF“ position.
Remove the plug from the mains socket if you will not be using the unit for an extended period of
time. Place the unit so that the plug can be easily removed.
Note
16
PHONOPHONO
EARTH
LR
LR
Amplifier (not included)
Back of main unit
PHONOcable
AC mains lead
PHONO earth lead
To a household
mains socket
SL-1200GR2EBTQBM0908.indd17SL-1200GR2EBTQBM0908.indd17 2023/06/3013:10:392023/06/3013:10:39

Technics SL-1200GR2 Specifications

General

Drive Method	Direct Drive
Motor	Coreless Direct Drive Motor
Effective Tonearm Length	230 mm
Overhang	15 mm
Tracking Force Adjustment Range	0 - 4 g (Direct Reading)
Power Consumption	11 W
Dimensions (W x H x D)	453 x 173 x 372 mm
Power Supply	AC120 V, 60 Hz
Turntable Platter	Aluminum Die-cast
Speeds	33-1/3 rpm, 45 rpm, 78 rpm
Wow and Flutter	0.025% W.R.M.S.
Tonearm Type	Universal Static Balance
Headshell Weight	7.6 g
Applicable Cartridge Weight Range (without auxiliary weight)	5.6 - 12.0 g
Weight	11.5 kg
Signal-to-Noise Ratio	78 dB
Terminals	PHONO x 1, GND x 1
