Technics SL-1200GR2 User Manual

Getting started
Playing back
21
Playing records
1
Turn [ON/OFF] to turn the unit on.
The strobe light comes on. 33-1/3 rpm is
automatically selected and the indicator [33]
lights.
2
Press [START-STOP].
The turntable starts revolving.
Speed select buttons
Indicators
·
4
3
5
1
2
EP record adaptor
Centre spindle

1

2

2
Preparation

1 Put a record (not included) on the turntable.

2 Take off the stylus cover and release the arm clamp.
ピピ フブ
ヘベ
ヴヵモンヵ〔ヴヵヰヱ
ピピ
ɿ
ɿ
ɿ
ヌプハフ
チチピハピ
チチパ
ノ
チ
ピハピ
テ
Strobe light
Indicator
Attention
Do not press [START-STOP] when the turntable is removed.
If you have accidentally pressed [START-STOP].

The indicator of the speed select button ([33] or [45]) starts blinking.


If it is blinking, turn [ON/OFF] to turn the unit off, fit the turntable and then turn [ON/OFF] to turn
the unit on.
SL-1200GR2EBTQBM0908.indd22SL-1200GR2EBTQBM0908.indd22 2023/06/3013:10:442023/06/3013:10:44

Technics SL-1200GR2 Specifications

General

Drive Method	Direct Drive
Motor	Coreless Direct Drive Motor
Effective Tonearm Length	230 mm
Overhang	15 mm
Tracking Force Adjustment Range	0 - 4 g (Direct Reading)
Power Consumption	11 W
Dimensions (W x H x D)	453 x 173 x 372 mm
Power Supply	AC120 V, 60 Hz
Turntable Platter	Aluminum Die-cast
Speeds	33-1/3 rpm, 45 rpm, 78 rpm
Wow and Flutter	0.025% W.R.M.S.
Tonearm Type	Universal Static Balance
Headshell Weight	7.6 g
Applicable Cartridge Weight Range (without auxiliary weight)	5.6 - 12.0 g
Weight	11.5 kg
Signal-to-Noise Ratio	78 dB
Terminals	PHONO x 1, GND x 1
