3
Press [RESET] to light the pitch
control blue LED lamp.
The unit plays at a preset pitch (33-1/3, 45
or 78 rpm) regardless of the [PITCH ADJ]
position.
4
Lift the cue lever and move the
tone arm over the record.
5
Lower the cue lever slowly.
The tone arm moves down slowly.
Play starts.
Fine adjustment to
pitch (
23 )
When play finishes
Lift the cue lever, return the tone arm to the
arm rest and lower the cue lever.
Press [START-STOP].
The electronic brake gently stops the
turntable.
Turn [ON/OFF] to turn the unit off.
Clamp the tone arm with the arm clamp.
Put the stylus cover back on (to protect the
stylus tip).
To light up the stylus
The stylus tip is illuminated during play.
Stylus light
Stylus light switch
Press the stylus light switch.
The stylus light (white LED) rises up and
illuminates the stylus.
Press down the stylus light to turn off the
light.
Attention
Press the stylus light switch firmly. If the switch
is lightly pressed, the light may come on but not
rise up.
When playing EP records
Press the speed select button [45] ([45]
lights).
Fit the EP record adaptor over the centre
spindle.
When playing SP records
Press the speed select buttons [33] and [45]
at the same time (78 rpm: [33] and [45]
light).
When using a record stabilizer (not
included)
See the instruction manual of the record
stabilizer.
Maximum weight: 1 k
g
To temporarily stop play
Lift the cue lever.
The stylus lifts off the record.
To start play again, lower the cue lever.
RESET
button
Blue LED
indicator
Cue lever
22
Playing records
(continued)
