6 Error Code Display and Servo Adjustment
Function
TOP PREVIOUS NEXT
This unit has an error code display function, so that if the unit operates incorrectly, the fault is
displayed using an error code on the FL display of the Tuner/Amplifier (SA-EH560). It also has a
servo adjustment function for displayingthe status of servo system functions (Focus, Tracking, CLV
servo) on the FL display of the Tuner/Amplifier. The system control IC and FL display are part of the
Tuner/Amplifier so make sure the system has been connected properly beforeusing these functions.
Use these two functions for guidance during fault diagnosis and repair.
Note:
Check beforehand for scratching or soiling of the test disc (SZZP1054C), and soiling or other
problems with the pickup lens.
6.1 Error Code Display Procedure
6.1.1 Automatic Adjustment Results
6.1.2 Checking the mechanism switches
6.2 Servo Adjustment Procedure
6.3 Error code based on troubleshooting
•@
