16 Replacement Parts List
TOP PREVIOUS NEXT
Notes:
Important safety notice:
Components identified by
mark have special characteristics important for safety.
Furthermore, special parts which have purposes of fire-retardant (resistors), high-quality sound
(capacitors), low-noise (resistors), etc. are used.
When replacing any of components, be sure to use only manufacture’s specified parts shown in the
parts list.
The marking [RTL] indicates that Retention Time is Limited for this item. After the discontinuation
of this assembly in production, the item will continue to be available for a specific period of time.
The retention period of availabilityis dependent on the type of assembly, and in accordance with the
laws governing part and product retention. After the end of this period, the assembly will no longer
be available.
All parts are supplied by MESA.
Ref. No. Part No. Part Name& Description Pcs Remarks
1 RKM0400-1S TOP CABINET 1
2 RHD30007-S SCREW 4
3 XTBS3+8JFZ1 SCREW 1
4 REX0976 CONNECTOR ASS’Y(6P) 1
5 RGK1136-1S TRAY ORNAMENT 1
6 RKA0105-K RUBBER 4
7 RKA0106-N FOOT RING 4
8 RYP0897A-1S FRONT PANEL ASS’Y 1
8-1 RGB0025-A TECHNICS BADGE 1
9 XTBS3+8JFZ1 SCREW 3
10 XTB3+8FFZ SCREW 2
11 REZ1199 FFC 1
