101 RFKJXDT07-K LOADING CHASSIS ASS’Y 1
101-1 RDG0142 GEAR 1
101-2 RDG0193 GEAR 1
101-3 RDP0065 PULLEY 1
102 REM0019 MOTOR ASS’Y 1
103 RMK0255 BELT COVER 1
104 RGQ0144-K DISC TRAY 1
105 RAE0152Z-1 TRAVERSE DECK ASS’Y 1
105-1 SHGD113-1 FLOATING RUBBER 3
105-2 SNSD38 SCREW 2
105-3 RAF0150A-1 OPTICAL PICK-UP 1
105-4 RDG0247 DRIVE GEAR 1
105-5 RDG0248 GEAR 1
105-6 RXQ0339 TRAVERSE MOTOR 1
105-7 RXQ0304-1 PLATE 1
105-8 XQN17+CG5 SCREW 1
105-9 XQN2+CQ5 SCREW 1
105-10 XQS17+A35FZ SCREW 2
106 RMS0350-1 PIN(A) 1
107 RMS0627 PIN(B) 1
108 RME0109 SPRING(A) 2
109 RME0142 SPRING(B) 1
110 RMR0698-K1 TRAVERSE CHASSIS 1
111 XTV2+6G SCREW 2
112 RME0063 SPRING 1
113 RMM0079-1 SLIDE PLATE(1) 1
114 RML0178-1 LEVER 1
115 RFKNLPG440-K GEAR ASS’Y 1
116 RHD20009-1 SCREW 1
117 RME0087 SPRING 1
118 RML0349 LEVER 1
119 RMM0059-1 SLIDE PLATE(2) 1
120 RMR0334 HOLDER 1
121 RHM245ZA MAGNET 1
